Welcome to Webhooks in Neuro

Webhooks are Neuro’s way of tapping you on the shoulder the moment something important happens.

Instead of repeatedly polling our API to find out whether an order has arrived, a fulfilment has been created, or stock has changed, webhooks let Neuro push that information straight into your systems in real time. You give us a URL; we send you rich JSON payloads whenever key events occur across orders, fulfilments, products, and invoices.

This makes life easier in a few very practical ways:

• You keep external systems perfectly in sync without writing brittle polling jobs or cron tasks.

• You can trigger downstream workflows instantly – update your WMS, notify a 3PL, create accounting entries, or send internal alerts the moment data changes.

• You get a consistent, well‑structured payload shape for each entity type, so parsing and mapping data is predictable and repeatable.

This page is your complete field reference for those payloads. For every webhook we fire, you’ll find the event name, when it triggers, the JSON body you can expect, and a description of each field so you can confidently validate, transform, and use the data in your own applications and integrations.

1. Webhook Events at a Glance

Neuro emits outbound webhooks whenever key entities change. Each event always sends a full snapshot of the entity at that moment, not a diff.

Item limits:

Order events include up to 150 items per payload, product events up to 250. Larger orders/products are split into multiple webhook calls.

2. Orders Received (orders.received)

Fired when a new order is imported from a channel into Neuro. Order webhooks all share the same Order payload shape. Only the triggering context differs.

2.1 Example: ‎`orders.received` Payload

Triggered when a new order is imported into Neuro.

Payload: Order

{
  "webhook_id": "a1b2c3d4-0000-0000-0000-000000000001",
  "order_id": "f7e6d5c4-1111-2222-3333-444444444444",
  "channel_id": "c1d2e3f4-aaaa-bbbb-cccc-dddddddddddd",
  "channel_alt_id": "ALT-12345",
  "channel_name": "My Shopify Store",
  "channel_type": "shopify",
  "store_id": "s1t2o3r4-eeee-ffff-0000-111111111111",
  "remote_id": "5678901234",
  "remote_status": "Unshipped",
  "status": "Unshipped",
  "customer": {
    "id": 12345,
    "customer_uuid": "cust-uuid-0001",
    "company_id": 1,
    "name": "Jane Smith",
    "email": "jane.smith@example.com",
    "created_at": "2025-06-10T08:00:00.000000Z",
    "updated_at": "2026-01-15T14:32:00.000000Z"
  },
  "shipping_method": "Standard Shipping",
  "shipping_address": {
    "id": "addr-uuid-ship-001",
    "name": "Jane Smith",
    "company_name": "Acme Ltd",
    "address_line_one": "123 High Street",
    "address_line_two": "Floor 2",
    "address_line_three": "",
    "long_address": "123 High Street, Floor 2",
    "county": "Greater London",
    "city": "London",
    "country_iso_code": "GB",
    "zip": "EC1A 1BB",
    "phone": "+441234567890"
  },
  "invoice_address": {
    "id": "addr-uuid-inv-001",
    "name": "Jane Smith",
    "company_name": "Acme Ltd",
    "address_line_one": "123 High Street",
    "address_line_two": "",
    "address_line_three": "",
    "long_address": "123 High Street",
    "county": "Greater London",
    "city": "London",
    "country_iso_code": "GB",
    "zip": "EC1A 1BB",
    "phone": "+441234567890"
  },
  "fulfillment": null,
  "return": null,
  "payment_method": "shopify_payments",
  "send_via_webhook": true,
  "payment_status": "paid",
  "payment_details": {
    "vat_id": "",
    "vat_type": null,
    "tax_rate": "20",
    "tax_total": "8.33",
    "shipping_total": "4.99",
    "discount_total": "0",
    "discount_total_exc_tax": "0",
    "order_subtotal": "41.65",
    "order_subtotal_exc_tax": "33.32",
    "order_total": "46.64",
    "payment_method": "shopify_payments",
    "payment_ref": "ch_3ABC123",
    "payment_currency": "GBP",
    "coupon_code": "",
    "coupon_total": "0",
    "coupon_total_exc_tax": "0"
  },
  "system_notes": "",
  "delivery_notes": "Please leave at the door",
  "customer_comments": "",
  "gift_note": "",
  "channel_specific": {
    "shipping_code": "shopify-Standard Shipping-4.99",
    "tags": ["VIP", "wholesale"],
    "note_attributes": [
      { "name": "gift_message", "value": "Happy Birthday!" }
    ]
  },
  "order_access_url": "https://myshop.myshopify.com/admin/orders/5678901234",
  "order_date": "2026-01-15T14:32:00.000000Z",
  "order_import_date": "2026-01-15T14:33:12.000000Z",
  "total_order_item_quantity": 2,
  "total_order_item_quantity_inc_kits": 4,
  "primary_reference_id": null,
  "order_lines": [
    {
      "id": "item-uuid-0001",
      "remote_id": "li_123456",
      "sku": "WIDGET-BLU-M",
      "channel_product_id": "cp-uuid-0001",
      "master_product_id": "mp-uuid-0001",
      "matched_sku": "WIDGET-BLU-M",
      "quantity": 1,
      "refunded_quantity": 0,
      "name": "Blue Widget (Medium)",
      "unit_price": "20.83",
      "unit_price_exc_tax": "16.66",
      "unit_discount": "0.00",
      "total_discount": "0.00",
      "unit_tax_rate": "20.02",
      "unit_tax_value": "4.17",
      "total_tax_value": "4.17",
      "total_price": "20.83",
      "is_tax_included": true,
      "options": null,
      "image_url": "https://cdn.example.com/widget-blue.jpg",
      "file_url": null,
      "notes": null
    },
    {
      "id": "item-uuid-0002",
      "remote_id": "li_123457",
      "sku": "KIT-STARTER",
      "channel_product_id": "cp-uuid-0002",
      "master_product_id": "mp-uuid-0002",
      "matched_sku": "KIT-STARTER",
      "quantity": 1,
      "refunded_quantity": 0,
      "name": "Starter Kit",
      "unit_price": "20.82",
      "unit_price_exc_tax": "16.66",
      "unit_discount": "0.00",
      "total_discount": "0.00",
      "unit_tax_rate": "19.93",
      "unit_tax_value": "4.16",
      "total_tax_value": "4.16",
      "total_price": "20.82",
      "is_tax_included": true,
      "options": null,
      "image_url": "https://cdn.example.com/kit-starter.jpg",
      "file_url": null,
      "notes": null,
      "kit": [
        { "quantity": 1, "sku": "WIDGET-RED-S", "name": "Red Widget (Small)" },
        { "quantity": 2, "sku": "WIDGET-GRN-S", "name": "Green Widget (Small)" }
      ]
    }
  ],
  "md5_hash": "a1b2c3d4e5f6a7b8c9d0e1f2a3b4c5d6"
}

Order Field Reference

2.2 Other Order Events (Same Payload, Different Moment)

These events reuse the exact Order structure:

• ‎`orders.updated` – order state changed (status, addresses, items, etc.)

  • Payload: Identical structure to orders.received. (The payload always sends the full current state of the order, not a diff. The webhook_id will be different from the original received webhook.)

• ‎`orders.on_hold` – order placed on hold

  • Payload: Identical structure to orders.received.

• ‎`orders.excluded` – order excluded (e.g. fraud, internal rules)

  • Payload: Identical structure to orders.received.


  Note: For orders.received, orders.route_to_webhook, and orders.excluded, fully refunded line items are excluded from order_lines.

• ‎`orders.route_to_webhook` – order directed to a routing-specific endpoint

  • Payload: Identical structure to orders.received.

• ‎`confirmation.orders.received` – confirmation that Neuro has processed the order, used for acknowledgement workflows.

  • Payload: Identical structure to orders.received.

For ‎`orders.received`, ‎`orders.route_to_webhook`, and ‎`orders.excluded`, fully refunded line items are omitted from ‎`order_lines`.

3. Fulfilments Created (fulfillments.created)

Fired when a new fulfilment is created for an order. Fulfilment events encapsulate shipment details plus a nested snapshot of the parent order.

3.1 Example: ‎`fulfillments.created` Payload

Triggered when a new fulfilment is created.

Payload: Fulfilment

{
  "id": "ff-uuid-0001",
  "order_id": "f7e6d5c4-1111-2222-3333-444444444444",
  "order_primary_reference_id": null,
  "order_remote_id": "5678901234",
  "order_remote_alt_id": "ALT-12345",
  "courier": {
    "id": "cc-uuid-0001",
    "name": "Royal Mail",
    "custom_name": "RM Tracked 24"
  },
  "shipping_method": "Royal Mail Tracked 24",
  "shipping_tracking_code": "JD012345678GB",
  "tracking_url": "https://www.royalmail.com/track-your-item#/tracking-results/JD012345678GB",
  "fulfillment_date": "2026-02-18 00:05:16",
  "sync_status": 2,
  "items": [
    { "sku": "WIDGET-BLU-M", "quantity": 1, "sales_channel_item_id": "5468632165489" }
  ],
  "order_items": [
    {
      "remote_id": "li_123456",
      "sku": "WIDGET-BLU-M",
      "quantity": 1
    }
  ],
  "order": {
    "order_id": "f7e6d5c4-1111-2222-3333-444444444444",
    "channel_id": "c1d2e3f4-aaaa-bbbb-cccc-dddddddddddd",
    "channel_alt_id": "ALT-12345",
    "channel_name": "My Shopify Store",
    "channel_type": "shopify",
    "store_id": "s1t2o3r4-eeee-ffff-0000-111111111111",
    "remote_id": "5678901234",
    "remote_status": "fulfilled",
    "status": "fulfilled",
    "customer": {
      "id": 12345,
      "customer_uuid": "cust-uuid-0001",
      "company_id": 1,
      "name": "Jane Smith",
      "email": "jane.smith@example.com",
      "created_at": "2025-06-10T08:00:00.000000Z",
      "updated_at": "2026-01-15T14:32:00.000000Z"
    },
    "shipping_method": "Standard Shipping",
    "shipping_address": {
      "id": "addr-uuid-ship-001",
      "name": "Jane Smith",
      "company_name": "Acme Ltd",
      "address_line_one": "123 High Street",
      "address_line_two": "Floor 2",
      "address_line_three": "",
      "long_address": "123 High Street, Floor 2",
      "county": "Greater London",
      "city": "London",
      "country_iso_code": "GB",
      "zip": "EC1A 1BB",
      "phone": "+441234567890"
    },
    "invoice_address": {
      "id": "addr-uuid-inv-001",
      "name": "Jane Smith",
      "company_name": "Acme Ltd",
      "address_line_one": "123 High Street",
      "address_line_two": "",
      "address_line_three": "",
      "long_address": "123 High Street",
      "county": "Greater London",
      "city": "London",
      "country_iso_code": "GB",
      "zip": "EC1A 1BB",
      "phone": "+441234567890"
    },
    "return": null,
    "payment_method": "shopify_payments",
    "send_via_webhook": true,
    "payment_status": "paid",
    "payment_details": {
      "vat_id": "",
      "vat_type": "",
      "tax_total": "8.33",
      "shipping_total": "4.99",
      "discount_total": "0.00",
      "discount_total_exc_tax": "0.00",
      "order_subtotal": "41.65",
      "order_subtotal_exc_tax": "33.32",
      "order_total": "46.64",
      "payment_method": "shopify_payments",
      "payment_ref": "ch_3ABC123",
      "payment_currency": "GBP",
      "coupon_code": "",
      "coupon_total": "0.00",
      "coupon_total_exc_tax": "0.00"
    },
    "system_notes": "",
    "delivery_notes": "Please leave at the door",
    "customer_comments": "",
    "gift_note": "",
    "channel_specific": {
      "shipping_code": "shopify-Standard Shipping-4.99",
      "tags": ["VIP"],
      "is_pos_order": false,
      "order_number": 458754,
      "total_weight": 421,
      "shipping_code": "Free Express Tracked: 1-2 Days"
    },
    "order_access_url": "https://myshop.myshopify.com/admin/orders/5678901234",
    "order_date": "2026-01-15T14:32:00.000000Z",
    "order_import_date": "2026-01-15T14:33:12.000000Z",
    "total_order_item_quantity": 1,
    "total_order_item_quantity_inc_kits": 1,
    "primary_reference_id": null,
    "order_lines": [
      {
        "id": "item-uuid-0001",
        "remote_id": "li_123456",
        "sku": "WIDGET-BLU-M",
        "channel_product_id": "cp-uuid-0001",
        "master_product_id": "mp-uuid-0001",
        "matched_sku": "WIDGET-BLU-M",
        "quantity": 1,
        "refunded_quantity": 0,
        "name": "Blue Widget (Medium)",
        "unit_price": "20.83",
        "unit_price_exc_tax": "16.66",
        "unit_discount": "0.00",
        "total_discount": "0.00",
        "unit_tax_rate": "20.02",
        "unit_tax_value": "4.17",
        "total_tax_value": "4.17",
        "total_price": "20.83",
        "is_tax_included": true,
        "options": [
                {
                  "option_name": "__kaching_bundles",
                  "option_value": {
                    "deal": "7tD45m",
                    "main": true,
                    "market": 5455,
                    "id": "ANtp"
                  }
                }
              ],
        "image_url": "https://cdn.example.com/widget-blue.jpg",
        "file_url": null,
        "notes": null
      }
    ],
    "md5_hash": "a1b2c3d4e5f6a7b8c9d0e1f2a3b4c5d6"
  },
  "plugin": {
    "id": "plg-uuid-0001",
    "name": "Whistl 3PL"
  },
  "channel": {
    "id": "c1d2e3f4-aaaa-bbbb-cccc-dddddddddddd",
    "name": "My Shopify Store"
  },
  "fulfillment_plugin": {
    "id": "plg-uuid-0001",
    "name": "Whistl 3PL"
  }
}

Fulfilment Field Reference

‎Fulfilments Updated

Fired when an existing fulfilment is updated (tracking code changed, status updated, etc.). `fulfillments.updated` uses the same structure; only values change (e.g. tracking code).

Payload: Identical structure to fulfillments.created.

4. Product & Stock Webhooks

Two layers of product data are exposed: master products, channel products, and plugin products.

4.1 Master Products – ‎`products.updated`

Triggered when a main product changes (stock, title, etc.).

4.2 Products Created (products.created)

Coming Soon — This event will be available in an upcoming release.

Fired when a new main (master) product is created in Neuro.

4.3 Products Updated (products.updated)

Fired when a main (master) product is updated (stock quantity change, title change, etc.).

Payload: Product

{
  "id": "mp-uuid-1001",
  "sku": "TSHIRT-BLK-L",
  "title": "Classic T-Shirt Black (Large)",
  "product_nominal_code": "4000",
  "tax_type": "standard",
  "quantity": 150,
  "price": "24.99",
  "plugin_quantity": 150,
  "plugin_quantity_synced_at": "2026-01-15T08:00:00.000000Z",
  "plugin_sync_status": 2,
  "plugin_synced_at": "2026-01-15T08:00:00.000000Z",
  "api_quantity": 0,
  "type": "product",
  "auto_sync_stock": true,
  "product_kit_items": [],
  "channels": [
    {
      "id": "cp-uuid-1001",
      "type": "product",
      "store_id": "store-uuid-001",
      "store_name": "My Store",
      "channel_id": "ch-uuid-shopify",
      "channel_name": "My Shopify Store",
      "remote_id": "7654321098765",
      "remote_sku": "TSHIRT-BLK-L",
      "sku": "TSHIRT-BLK-L",
      "matched_sku": "TSHIRT-BLK-L",
      "title": "Classic T-Shirt Black (Large)",
      "description": "A classic black t-shirt in size large.",
      "image_url": "https://cdn.shopify.com/s/files/tshirt-black.jpg",
      "pending_quantity": 148,
      "synced_quantity": 148,
      "quantity": 150,
      "price": "24.99",
      "currency": "GBP",
      "product_nominal_code": "4000",
      "dimensions": {
        "weight": 0.35,
        "weight_unit": "kg",
        "length": 30.0,
        "length_unit": "cm",
        "width": 25.0,
        "width_unit": "cm",
        "height": 2.0,
        "height_unit": "cm"
      },
      "export": {
        "hs_code": "6109.10.00",
        "country_of_origin": "GB",
        "customs_description": "Cotton T-Shirt"
      },
      "barcodes": [
        {
          "id": 1,
          "barcode": "5060000000001"
        }
      ],
      "use_low_stock_buffer": false,
      "low_stock_buffer": 0,
      "channel_product_url": "https://myshop.myshopify.com/admin/products/7654321098765"
    }
  ],
  "plugin_products": [
    {
      "id": "pp-uuid-0001",
      "store_id": "store-uuid-001",
      "store_name": "My Store",
      "remote_id": "IP-98765",
      "sku": "TSHIRT-BLK-L",
      "product_id": 101,
      "quantity": 150,
      "plugin_sync_status": 2,
      "plugin_synced_at": "2026-01-15T08:00:00.000000Z",
      "title": "Classic T-Shirt Black (Large)",
      "image_url": "",
      "created_at": "2025-06-01T10:00:00.000000Z",
      "updated_at": "2026-01-15T08:00:00.000000Z",
      "plugin": {
        "id": "a0c745fd-d344-48ab-b520-54985314654",
        "name": "my amazon plugin",
        "provider_type": "amazon_mcf",
        "push_orders": true,
        "use_max_order_limit": false,
        "max_order_limit": 0,
        "max_order_sent_days": 0,
        "max_order_status": 0,
        "is_active": true,
        "is_connected": true,
        "allow_order_split": false,
        "is_default": false,
        "push_order_cancellation_data": false,
        "last_push_order_cancellation_data_at": null,
        "refetch_fulfillment": false,
        "channels": [
          {
            "id": "f38f9610-8d5b-1232-a19f-6f610289af4c",
            "name": "My Shopify Store"
          }
        ]
      }
    }
  ]
}

Product Field Reference

Product with Kit Items Example

When type is kit:

{
  "id": "mp-uuid-2001",
  "sku": "KIT-STARTER",
  "title": "Starter Kit",
  "product_nominal_code": "",
  "tax_type": "standard",
  "quantity": 50,
  "price": "39.99",
  "plugin_quantity": 0,
  "plugin_quantity_synced_at": null,
  "plugin_sync_status": 0,
  "plugin_synced_at": null,
  "api_quantity": 0,
  "type": "kit",
  "auto_sync_stock": true,
  "product_kit_items": [
    {
      "id": "mp-uuid-3001",
      "sku": "WIDGET-RED-S",
      "quantity": 1,
      "name": "Red Widget (Small)"
    },
    {
      "id": "mp-uuid-3002",
      "sku": "WIDGET-GRN-S",
      "quantity": 2,
      "name": "Green Widget (Small)"
    }
  ],
  "channels": [],
  "plugin_products": []
}

When ‎`type` is ‎`kit`, the ‎`product_kit_items` array describes the component SKUs and quantities instead of direct stock.

5. Channels Products Created (channels.products.created)

Coming Soon — This event will be available in an upcoming release.

Activated when a new channel product is created (e.g. imported from a sales channel into Neuro).

Payload: Identical structure to channels.products.updated.

5.1 Channels Products Updated (channels.products.updated)

Represents how a product appears on a specific sales channel. Activated when a channel product is updated (stock sync, quantity change, price update, etc.).

Payload: Channel Product

{
  "id": "cp-uuid-1001",
  "type": "product",
  "store_id": "store-uuid-001",
  "store_name": "My Store",
  "channel_id": "ch-uuid-shopify",
  "channel_name": "My Shopify Store",
  "remote_id": "7654321098765",
  "remote_sku": "TSHIRT-BLK-L",
  "sku": "TSHIRT-BLK-L",
  "matched_sku": "TSHIRT-BLK-L",
  "title": "Classic T-Shirt Black (Large)",
  "description": "A classic black t-shirt in size large.",
  "image_url": "https://cdn.shopify.com/s/files/tshirt-black.jpg",
  "pending_quantity": 148,
  "synced_quantity": 148,
  "quantity": 150,
  "price": "24.99",
  "currency": "GBP",
  "product_nominal_code": "4000",
  "dimensions": {
    "weight": 0.35,
    "weight_unit": "kg",
    "length": 30.0,
    "length_unit": "cm",
    "width": 25.0,
    "width_unit": "cm",
    "height": 2.0,
    "height_unit": "cm"
  },
  "export": {
    "hs_code": "6109.10.00",
    "country_of_origin": "GB",
    "customs_description": "Cotton T-Shirt"
  },
  "barcodes": [
    { "id": 1, "barcode": "5060000000001" }
  ],
  "meta_fields": null,
  "use_low_stock_buffer": false,
  "low_stock_buffer": 0,
  "channel_product_url": "https://myshop.myshopify.com/admin/products/7654321098765"
}

Channel Product Field Reference

6. Plugin Products

Represents product state on a plugin (e.g. Inventory Planner, 3PL, etc.).

6.1 Plugins Products Created (plugins.products.created)

Coming Soon — This event will be available in an upcoming release.

Fired when a new plugin product is created in Neuro.

Payload: Identical structure to plugins.products.updated.

6.2 Plugins Products Updated (plugins.products.updated)

Fired when a plugin product is updated.

Payload: Plugin Product

{
  "id": "pp-uuid-0001",
  "store_id": "store-uuid-001",
  "store_name": "My Store",
  "remote_id": "IP-98765",
  "sku": "TSHIRT-BLK-L",
  "product_id": 101,
  "quantity": 150,
  "plugin_sync_status": 2,
  "plugin_synced_at": "2026-01-15T08:00:00.000000Z",
  "title": "Classic T-Shirt Black (Large)",
  "image_url": "",
  "created_at": "2025-06-01T10:00:00.000000Z",
  "updated_at": "2026-01-15T08:00:00.000000Z",
  "product": {
    "id": "mp-uuid-1001",
    "sku": "TSHIRT-BLK-L",
    "title": "Classic T-Shirt Black (Large)",
    "product_nominal_code": "4000",
    "tax_type": "standard",
    "quantity": 150,
    "price": "24.99",
    "plugin_quantity": 150,
    "plugin_quantity_synced_at": "2026-01-15T08:00:00.000000Z",
    "plugin_sync_status": 2,
    "plugin_synced_at": "2026-01-15T08:00:00.000000Z",
    "api_quantity": 0,
    "type": "product",
    "auto_sync_stock": true,
    "product_kit_items": [],
    "channels": [],
    "plugin_products": []
  },
  "plugin": {
    "id": "plg-uuid-0001",
    "name": "Inventory Planner",
    "provider_type": "inventory_planner",
    "push_orders": true,
    "use_max_order_limit": false,
    "max_order_limit": 0,
    "max_order_sent_days": 30,
    "max_order_status": 0,
    "is_active": true,
    "is_connected": true,
    "push_order_cancellation_data": false,
    "last_push_order_cancellation_data_at": null
  }
}

Plugin Product Field Reference

7. Invoices Received (invoices.received)

Invoices are emitted when financial records are created or updated. Activated when a new invoice is received / created.

7.1 Example: ‎`invoices.received`

Payload: Invoice

{
  "id": "inv-uuid-0001",
  "invoice_number": "INV-2026-0042",
  "order_id": 500,
  "currency": "GBP",
  "store_id": "store-uuid-001",
  "channel_id": "ch-uuid-shopify",
  "shipping_total": "4.99",
  "shipping_tax_type": "standard",
  "shipping_account_code": "4200",
  "notes": "Monthly recurring order",
  "total": "46.64",
  "invoice_date": "2026-01-15T00:00:00.000000Z",
  "due_date": "2026-02-14T00:00:00.000000Z",
  "notify_contact": true,
  "meta": null,
  "sync_status": 0,
  "status": "pending",
  "lines": [
    {
      "id": "invl-uuid-0001",
      "product_nominal_code": "4000",
      "product": {
        "id": "mp-uuid-1001",
        "sku": "WIDGET-BLU-M",
        "title": "Blue Widget (Medium)",
        "product_nominal_code": "4000",
        "tax_type": "standard",
        "quantity": 150,
        "price": "20.83",
        "plugin_quantity": 150,
        "plugin_quantity_synced_at": "2026-01-15T08:00:00.000000Z",
        "plugin_sync_status": 2,
        "plugin_synced_at": "2026-01-15T08:00:00.000000Z",
        "api_quantity": 0,
        "type": "product",
        "auto_sync_stock": true,
        "product_kit_items": [],
        "channels": [],
        "plugin_products": []
      },
      "sku": "WIDGET-BLU-M",
      "description": "Blue Widget (Medium) x1",
      "tax_type": "standard",
      "quantity": 1,
      "unit_price": "16.66",
      "price": "20.83",
      "discount_total": "0.00",
      "tax_total": "4.17"
    }
  ],
  "customer": {
    "id": 12345,
    "customer_uuid": "cust-uuid-0001",
    "company_id": 1,
    "name": "Jane Smith",
    "email": "jane.smith@example.com",
    "created_at": "2025-06-10T08:00:00.000000Z",
    "updated_at": "2026-01-15T14:32:00.000000Z"
  },
  "invoice_address": {
    "id": "addr-uuid-inv-001",
    "name": "Jane Smith",
    "company_name": "Acme Ltd",
    "address_line_one": "123 High Street",
    "address_line_two": "",
    "address_line_three": "",
    "long_address": "123 High Street",
    "county": "Greater London",
    "city": "London",
    "country_iso_code": "GB",
    "zip": "EC1A 1BB",
    "phone": "+441234567890"
  }
}

Invoice Field Reference

7.2 Invoices Updated (invoices.updated)

Fired when an existing invoice is updated.

Payload: Identical structure to invoices.received.

Whats Next

In the next article, we’ll unpack the exact data structures that sit inside your webhook deliveries, from channel-specific metadata to the shared customer, address, payment, and line-item objects that make up each order. To continue, open Order Payload Reference: Channel-Specific Fields and Shared Object Schemas and follow along from the start of the page.

All data in this document is fictitious. No real customer, order, address, or product data is used.
